Automatic modal hammer | vImpact-2003

With an impact force of up to 2500N, the vImpact-2003 automatic modal hammer is perfect for exciting larger components and machine parts.

Data sheet (EN)

Automatic modal hammer vImpact-2003 by MAUL-THEET

Description

The vImpact-2003 is an automatic modal hammer designed for precise and versatile applications.

The vImpact-2003 offers variable pulse strength adjustment and also features a timer mode that automatically triggers impacts at a configurable time interval. Furthermore, the end position of the hammer plunger can be freely adjusted, allowing easy setup of the hammer for different testing requirements.

The automatic modal hammer vImpact-2003 combines power and functionality, making it ideal for measurements on larger components or assemblies.

Advantages & Innovations

Automatic modal hammer vImpact Touch Controller by MAUL-THEET
  • High reproducibility
  • Bounce-free excitation
  • Adjustable impact forces up to 2.5kN (optionally up to 4kN)
  • Impact force adjustable from 1 to 100%
  • Frequency ranges up to 6kHz
  • Optimized for end-of-line testing
  • Easy positioning
  • Variable distance to the test object
  • Easy setup with zero-point positioning
  • Interchangeable force cells
  • Intuitive operation via the controller’s touchscreen
  • Plug and play
  • Can be controlled via USB through serial interface
  • vImpact remote software included
  • Suitable for measurements in clean rooms
  • Hit Counter
  • Countdown till hit in timer mode
  • DAkkS calibration (DIN EN ISO/IEC 17025) possible

Application & Integration

Automatic modal hammer vImpact-2003 (application) by MAUL-THEET
  • Quality control
  • End-of-line testing
  • Automated modal analysis without supervision
  • Material testing
  • Condition analysis
  • Process monitoring
  • Experimental modal analysis
  • Test stands
  • Damping determination
  • Frequency analysis
  • Sound analysis

Setup Automatic modal hammer

The new vImpact-63/64 and vImpact-2003/2004 have a setup mode in which the hammers move to the intended stop position. In this position, it is very easy to align the automatic modal hammers correctly.

MAUL-THEET Upgrade Program

Stay one step ahead with MAUL-THEET technology – We offer future-oriented solutions across all our product lines so you can always benefit from the latest innovations. Whether you’re looking to expand your current setup or transition to the newest generation of our systems, we offer attractive upgrade options with discounts of up to 40%.

You already have an automatic modal hammer from another manufacturer and would like to benefit from our upgrade program? No problem, we also exchange third-party devices for the latest MAUL-THEET models upon request – ensuring maximum precision, reliability, and ease of use.
