Description
The vImpact-2002 is an automatic modal hammer designed for precise and versatile applications.
The vImpact-2002 offers variable impulse strength adjustment and also features a timer mode in which impacts are automatically triggered at an adjustable time interval. Furthermore, the end position of the hammer plunger can be freely adjusted, allowing for easy setup of the hammer for different testing requirements.
The vImpact-2002 automatic modal hammer combines power and functionality, making it ideal for measurements on larger components or assemblies.
Advantages & Innovations
- High reproducibility
- Bounce-free excitation
- Non-destructive testing (NDT)
- Adjustable impact forces up to 2.5kN (optionally up to 4kN)
- Impact force adjustable from 1 to 100%
- Frequency ranges up to 6kHz
- Optimized for end-of-line testing
- Easy positioning
- Variable distance to the test object
- Easy setup with zero-point positioning
- Interchangeable force cells
- Intuitive operation via the controller’s touchscreen
- Plug and play
- Can be controlled via USB through serial interface
- vImpact remote software included
- Suitable for measurements in clean rooms
- Hit Counter
- Countdown till hit in timer mode
- DAkkS calibration (DIN EN ISO/IEC 17025) possible
Application & Integration
- Quality control
- End-of-line testing
- Automated modal analysis without supervision
- Material testing
- Condition analysis
- Process monitoring
- Experimental modal analysis
- Test stands
- Damping determination
- Frequency analysis
- Sound analysis
